CDM-840 Remote Router Revision 2
Ethernet-based Remote Product Management MN-CDM840
6–21
• VLAN Access Mode forces the Traffic Interface to carry traffic for only one user-
configured VLAN.
Access Port VLAN ID – Enter a valid numeric port ID, from 1 to 4095. This ID is valid only when
Working Mode is set as BPM and the VLAN Port Mode is set to Access.
When the VLAN Port Mode is set to Access, VLAN tagged packets from WAN to LAN having a
VLAN ID that matches the “Access Port VLAN ID” will have the outer VLAN tag removed and then
transmitted by the Traffic port. In this mode, packets coming in to the Traffic port in this mode
will be tagged with the “Access Port VLAN ID”. If the outermost VLAN tag IDs for WAN to LAN
packets do not
match the “Access Port VLAN ID”, they will be dropped.
Click the (Link to Working Mode Configuration Page) hyperlink to access the Configuration |
Network | Working Mode page (Sect.
6.4.4.5.3.3).
Click [Submit] to save.
