CDM-840 Remote Router Revision 2
Serial-based Remote Product Management MN-CDM840
7–14
Parameter
Type
Command
(Instruction
Code
& Qualifier)
Number of
Arguments for
Command or
Response to Query
Description of Arguments
(Note that all arguments are ASCII numeric codes from 48 and 57)
Response to
Command
(Target to
Controller)
Query
(Instruction
Code &
Qualifier)
Response to Query
(Target to Controller)
Rx
MODCOD
(cont.)
18=16-APSK 2/3
19=16-APSK 3/4
20=16-APSK 4/5
21=16-APSK 5/6
22=16-APSK 8/9
23=16-APSK 9/10
24=32-APSK ¾
25=32-APSK 4/5
26=32-APSK 5/6
27=32-APSK 8/9
28=32-APSK 9/10
29=reserved
30=reserved
31=reserved
32=auto (future - ACM only)
All other codes are invalid.
Example: <0/RMC=6’cr’
Rx Gold
Code
Sequence
Index
N/A
6 bytes
Command or Query.
Note: Only valid in DVB-S2 mode.
Sets or returns Rx Gold Code Sequence Index in the form xxxxxx, where:
xxxxxx = Gold Code Sequence index ( 0 to 262141 )
Example: <1/RGS=189063’cr’
RGS=
RGS?
RGS*
RGS#
RGS?
RGS=xxxxxx
Rx
Spectrum
Invert
N/A
1 byte
Query only.
Returns Rx Spectrum Invert in the form x, where:
0=Normal
1=Rx Spectrum Inverted
Example: <0/RSI?’cr’
RSI?
RSI*
RSI#
RSI?
RSI=x
(see Description of
Arguments)
