CDM-800 Gateway Router Revision 1

Updating Firmware MN-CDM800

4–3



See Chapter 6. SERIAL‐BASED REMOTE PRODUCT  MANAGEMENT for

information and instructions on using the CDM‐800 Serial Command Line

Interface.



E. Alternately,usetheCDM‐800Web ServerInterfacetoobtainthefirmwareinformation.



• UseanEthernethub,switch,ordirect

cableconnectiontoconnectthe

CDM‐800‘FE

’10/100Fas

tEthernet

porttothePC.



• On the PC: Use a Web browser(e.g.,  InternetExplorer) tolog in to the CDM‐800

WebServerInterfaceandaccessthe‘Admin|Firmware’page.Then,makenoteof

theSlot#1andSlot#2firmwarelo

ads:



SeeChapter5.ETHERNET‐BASEDREMOTEPRODUCTMANAGEMENTfor

information and instructions on using the CDM‐800 Web Server

Interface.



2. Next,createatemporaryfolder(subdirectory)ontheuserPCforthefirmwarearchive

download.



• Driveletter“c:”isusedintheseexamples.Anyvalid,writabledr

veletter

canbeused.



• Typicalforalltasks:Typethecommandwithoutquotes

,andthenpress

Entertoexecute.




