CDM-800 Gateway Router Revision 1

Serial-based Remote Product Management MN-CDM800

6–5

6.2.2.2 Target Address

InEIA‐232applications,thisvalueissetto0000.



The Target Address designates the packet destination. The Controller does not have its own address. After the

Controller sends a packet with the designated Target Address, the Target responds to the Controller, using this

same address, to indicate the source of the packet.

6.2.2.3 Address Delimiter

Thisisthe“forwardslash”character'/'(ASCIIcode47).

6.2.2.4 Instruction Code

Thisisathree‐characteralphabeticsequencethatidentifiesthemessagesubject.



Whereverpossible,theinstructioncod eshavebeenchosentohavesomesignificance–e.g.,MLCforManagementLinkConfiguration,

IPAforManagementIPAddress,etc.Thisaidsinthereadabilityofthemessage,shoulditbedisplayedinitsrawASCIIfor

m.



Onlyuppercasealphabeticcharactersmaybeused(‘A’to‘Z’,ASCIIcodes65‐90).


