KPA Ku-Band Indoor Solid-State Power Amplifier Revision 1

Appendix C MN/KPA.IOM

C–3

C.5 Packet Structure

Controller-to-Target

Start of Packet Target Address Address Delimiter Instruction Code Code Qualifier Optional Arguments End of Packet

ASCII code 60

(1 character)

(4 characters)

ASCII code 47

(1 character)

(3 characters)

= or ?

ASCII codes 61 or

(1 character)

(n characters)

Carriage Return

ASCII code 13

(1 character)

Example: <0412/MUT=1{CR}

Target-to-Controller

Start of Packet Target Address Address Delimiter Instruction Code Code Qualifier Optional Arguments End of Packet

ASCII code 62

(1 character)

(4 characters)

ASCII code 47

(1 character)

(3 characters)

=, ?, !, or *

ASCII codes

61, 63, 33, or 42

(1 character)

(From 0 to n

characters)

Carriage Return,

Line Feed

ASCII codes 13,10

(2 characters)

-OR-

Carriage Return,

Line Feed

ASCII codes 13,10

(3 characters)

Example: >0412/MUT=1{CR}{LF}

If it is an error message or an old remote command, ‘]’ will show at the end.

Example: >1?ATT_INVALID PARAMETER'cr''lf']

C.5.1 Start of Packet

Controller-to-Target: This is the character ‘<’ (ASCII code 60).

Target-to-Controller: This is the character ‘>’ (ASCII code 62).

Because this is used to provide a reliable indication of the start of packet, these two characters may not appear anywhere else within the

body of the message. The only exceptions are in command RMS and CMS where the response is “FWPWR=<19.0”.
