UT4500 Series Up Converter MN/UT4500.IOM

Remote Control Revision 2

IF In

Up Converter - IOM

(Backup Unit)

Up Converter - TSEQM

(On line)

RF Out

IF In

Load

BU EQ

LP Out

LP In

P1 - Pin 7

Out

(Closed When

EQ Faults)

LP Out

Load

Figure 23. 1:1 Redundant Configuration Diagram -

Single Source RF Input with IOM-XX and TSEQM-XX Installed

Figure 24. TSEQM Connection Locations

J3 HSB

LP IN

LP OUT

J10

EQ OUT

J11

EQ IN

LP OUT

LP IN

RF OUT
