Ku-Band Satellite Transceiver Revision 9
FSK Remote Control Commands MN/KST2000AB.IOM
E-18
Parameter
Type
Command
(Instruction
Code and
qualifier)
Arguments for
Command or
Response to
Query
Description of arguments
(note that all arguments are ASCII numeric codes, that is, ASCII
codes between 48 and 57)
Response to Command (target to
controller)
Query
(Instruction
Code and
qualifier)
Configuration
Lock
LOC= 1 byte Command or Query
<add/LOC=x’cr’
>add/LOC=’cr’’lf’
<add/LOC?’cr’
>add/LOC=x’cr’’lf’
Where: X = 0 (Unlock)
1 (Lock)
LOK= (message ok)
LOK? (received ok, but invalid
arguments found)
LOK* (message ok, but not permitted in
current mode)
LOC?
Concise Up
Converter Status
n.a. 4 bytes Query only.
<add/CUS?’cr’
>add/CUS=ABCD’cr’’lf’
Where: A=Overtemperature Status, 0=OK, 1=FLT
B=L-Band Synthesizer Lock Status, 0=OK, 1=FLT
C=Ku-Band Synthesizer Lock Status, 0=OK, 1=FLT
D=Interprocessor Comm. Status, 0=OK, 1=FLT
CUS= (message ok)
CUS? (received ok, but invalid
arguments found)
CUS* (message ok, but not permitted in
current mode)
CUS?
Concise Down
Converter Status
n.a. 4 bytes Query only.
<add/CDS?’cr’
>add/CDS=ABCD’cr’’lf’
Where: A=Overtemperature Status, 0=OK, 1=FLT
B=L-Band Synthesizer Lock Status, 0=OK, 1=FLT
C=Ku-Band Synthesizer Lock Status, 0=OK, 1=FLT
D=Interprocessor Comm. Status, 0=OK, 1=FLT
CDS= (message ok)
CDS? (received ok, but invalid
arguments found)
CDS* (message ok, but not permitted in
current mode)
CDS?
Concise HPA
Status
n.a. 5 bytes Query only.
<add/CHS?’cr’
>add/CHS=ABCDE’cr’’lf’
Where: A=Overtemperature Status, 0=OK, 1=FLT, 2=NA
B=9.75V Status, 0=OK, 1=FLT, 2=NA
C=-5V Status, 0=OK, 1=FLT, 2=NA
D=BIAS Voltage Summary Status, 0=OK, 1=FLT, 2=NA
E=Interprocessor Comm. Status, 0=OK, 1=FLT, 2=NA
Note: Item D is the logical OR (shown as 1 or 0) of all the bias voltage
status information as shown:
CHS= (message ok)
CHS? (received ok, but invalid
arguments found)
CHS* (message ok, but not permitted in
current mode)
CHS?
